FT-IR spectrometer is an analytical instrument that uses an interferometer to modulate infrared light and obtains the infrared absorption spectrum of substances through Fourier transform. It is primarily used to identify chemical components of unknown substances(Such as organic compounds and polymer materials) and analyze molecular structures and chemical bonds. Widely applied in fields including chemistry, materials science, environmental monitoring, and food safety.
Ask about availability, configuration and delivery to your location. We reply personally.
Enquiry only. No payment is taken.Features:
1. Built with an industrial-grade temperature and humidity module, it features a digital display for real-time readings and a humidity alarm to effectively prevent damage to core components from moisture.
2. Reusable 304 stainless steel desiccant cartridge allows for easy replacement without opening the lid.
3. Utilizes a modified Michelson interferometer with a non-orthogonal design, significantly improving energy efficiency.
4. Employs a 3D orthogonal gold-coated mirror optical compensation system, ensuring permanent optical alignment without dynamic adjustment of the fixed mirror.
5. The sliding sample compartment door minimizes interference from atmospheric water vapor and carbon dioxide during testing.
6. Includes a standard spectral library of ~1,800 spectra. Additionally, a wide range of specialized infrared libraries(About 220,000 spectra) are available to support various industries. Users can also create custom libraries.
7. Features a 24W SiC globar IR source with electronic voltage stabilization and digital power supply, ensuring extended service life.
8. Offers multiple beam splitter options: KBr, ZnSe, CaF2, all using reliable moisture-resistant materials.
Technical Parameters:
| Model | BKFT-20 |
| Detector | DLATGS |
| Spectral Range | 7800~350cm-1 |
| Resolution | Better than 1cm-1 |
| Signal-to-noise Ratio | 30000:1 (P-P value, 4cm-1, 1min scan) |
| Wave Number Accuracy | Better than 0.01cm-1 |
| Transmission Accuracy | Better than 0.05 τ% |
| Beam Splitter | KBr substrate with germanium coating(Imported) |
| Interferometer | Non-orthogonal Michelson interferometer |
| Data Transmission Interface | High-speed USB2.0(Compatible with USB3.0) |
| Compatible Operating System | Windows XP, Windows Vista, Windows7, 8, 10, 11 |
| Environment Conditions | Temperature: 15~30℃
Humidity: 15~60% |
| Consumption | 12V24W |
| Standard Accessory | Operating software; sample holder; spare desiccant |
| Optional Accessory | FDA 21 CFR Part 11 compliance software; ZnSe crystal ATR; press; sheet mold; agate mortar; KBr spectral purity; gas pool; detachable liquid tank; fixed liquid pool; intelligent electronic moisture-proof box
Among them, the electronic moisture-proof box is mandatory optional attachment |
| Power Supply | AC 100~240V, 50/60Hz |
| Sample Bin Size | 190*160mm |
| External Size(W*D*H) | 450*350*210mm |
| Package Size(W*D*H) | 750*630*590mm(Main unit + electronic moisture–proof box) |
| Net Weight | 14kg |
| Gross Weight | 60kg(Main unit + electronic moisture–proof box) |
