- Model
- BM-E50 / BM-E10 / BM-E01
- Weighing Accuracy(d)
- 0.005g / 0.001g / 0.0001g
- Moisture Readability
- 0.01% / 0.001% / 0.001%
- Moisture Range MC%
- 0.00%~100.00% / 0.000%~100.000% / 0.000%~100.000%
- Solid Content Range DC%
- 100.00%~0.00% / 100.000%~0.000% / 100.000%~0.000%
- Weight Sensor
- HBM strain gauge force / Electromagnetic force / Electromagnetic force
- Weighing Range
- 124g (optional 220g/300g)
- Calibration Method
- External weight calibration (Single-Point & Multi-Points)
- Repeatability
- ≤3d
- Heating Source
- Halogen lamp
- Temperature Sensor
- PT-1000 High-precision platinum-rhodium temperature sensor
- Heating Program
- Standard heating, step heating, rapid heating, soft heating
- Heating Temperature Rang
- 40~200℃
- Temperature Accuracy
- 0.1℃, PID control
- Heating Time Setting
- 1~99 minutes(1s interval)
- Stop Mode
- Timing, manual, automatic
- Data Storage
- 2004 sets
- Display Data
- MC%(Moisture), DC%(Solid content), ATRO dry, ATRO wet, sample weight, moisture weight, dryer sample weight, temperature, time, analysis curve
- Function
- Custom Measurement Method, U Disk System Upgrade
- Display& Operating
- 5-inch LCD touch screen
- Sample Tray(去掉）
- 50 aluminum sample trays with 90mm diameter, optional stainless steel sample tray(去掉）
- Sample Height
- 24.5mm
- Sample Pan（Standard）
- Aluminum Sample Pan(50pcs), Stainless Steel Sample Pan(4pcs)
- Thermal Protection
- Aluminum High Temperature Radiator
- Baud rate
- 2400,4800,9600,19200
- Data Communication
- RS232/RS485(can be connected to a computer, printer, PLC, etc.)
- Print Function
- Optional Printer (thermal, needle, adhesive, etc.)
- Use Environment
- 1~38℃ (18~25℃ ideal temperature)
- Consumption
- 500W
- Power Supply
- AC220/110V;50/60Hz
- External Size (W*D*H)
- 350*220*205mm
- Net Weight
- 5.8kg / 8.8kg / 8.8kg
- Packing Size(W*D*H)
- 520*380*410mm
- Gross Weight
- 7.5kg / 10kg / 10kg
