- Model
- BDF-86V28 / BDF-86V58 / BDF-86V65 / BDF-86V108
- Capacity
- 28L / 58L / 65L / 108L
- Temp. Range
- -40~-86℃
- Temp. Accuracy
- 0.1℃
- Temp. Uniformity
- ±3℃ / ±4℃ / ±3℃ / ±3℃
- Temp. Stability
- ≤6℃
- Recovery Time(Recover to -75℃ in an ambient temp. of 25℃)
- 20min / 25min / ≤15min / 20min
- Cooling Time(Cool down to -80℃ in an ambient temp. of 25℃)
- 120min / 160min / ≤240min / 120min
- Control System
- Microprocessor control
- Display
- LED
- Alarm
- High/low temperature alarm, controller failure alarm / High/low temperature alarm, power failure alarm(48h), controller failure alarm, door ajar alarm,ambient temperature alarm, condenser fault alarm, filter clogging alarm, voltage abnormality alarm / High/low temperature alarm, power failure alarm(72h), controller failure alarm, door ajar alarm / High/low temperature alarm, controller failure alarm
- Refrigeration Type
- Direct-cooling
- Refrigerant
- R290/R170, 100g / R4001, 200g / R600a/R1150/R14, 150g / R290/R170, 115g
- Compressor
- International famous brand compressor /1
- Condenser & Evaporator
- Copper tube finned type; built-in coil type / Copper tube evaporator; finned condenser / Micro channel condenser; built-in coil type / Copper tube finned type; built-in coil type
- Defrost
- Manual defrost
- Construction
- Polyurethane cyclopentane foam
- Material
- Internal Material / 304 stainless steel / 304 stainless steel / 304 stainless steel
- Material
- External Material / Sprayed steel plate / Sprayed steel plate / Sprayed steel plate
- Door
- Outer door: cyclopentane monomer foam outer door*1Interior door: stainless steel door*1 / Outer door: sprayed steel plate door*1Interior door: stainless steel door*2 / Outer door: cyclopentane monomer foam outer door*1Interior door: cyclopentane monolithic foaming, stainless steel door*1 / Outer door: cyclopentane monomer foam outer door*1Interior door: stainless steel door*2
- Noise
- 55~60dB(A) / 58dB(A) / 53dB(A) / 55~60dB(A)
- Consumption
- 400W / 442W / 540WApparent power: 550VA / 480W
- Power Supply
- AC 220V, 50Hz(Standard); 220V, 60Hz; 110V, 50/60Hz(Optional) / AC 220V, 50Hz(Standard); 110/220V, 60Hz(Optional) / AC 220V, 50Hz(Standard); 220V, 60Hz; 110V, 50/60Hz(Optional) / AC 220V, 50Hz(Standard); 220V, 60Hz; 110V, 50/60Hz(Optional)
- Casters
- Yes
- Shelf
- 1
- Standard Accessory
- Test hole / Remote alarm function interface, test hole, USB interface / Test hole / Test hole
- Optional Accessory
- Temperature recorder / Temperature recorder, RS485, liquid nitrogen backup system / USB interface, RS485, temperature recorder, liquid nitrogen backup system / Temperature recorder
- Internal Size (W*D*H)
- 270*265*400mm / 330*453*410mm / 360*455*395mm / 460*460*510mm
- External Size (W*D*H)
- 505*520*1165mm / 635*757*1212mm / 660*715*1165mm / 700*730*1260mm
- Package Size (W*D*H)
- 535*575*1290mm / 730*860*1420mm / 765*825*1350mm / 765*815*1395mm
- Net Weight
- 71kg / 112kg / 92kg / 107kg
- Gross Weight
- 90kg / 146kg / 134kg / 133kg
