- Item
- Specification
- Model
- Auto-NGS 200
- Throughput
- 1~96
- Tiles number
- 25 standard tiles + (TIP off box + waste liquid area)
- Pipettor
- Specification: 200 µL; 24-channel (can be used as a single channel)Pipetting range: 50 µL tip: 1-200 µL; 200 µL tip: 2-200 µLMinimum detection volume: 20 µL
- Pipetting precision
- 1 µL: ≤8 %; 2 µL: ≤5 %; 5 µL: ≤4 %; 20 µL: ≤1 %; 100 µL: ≤1 %; 200 µL: ≤1 %
- Pipetting accuracy
- 1 µL: ±10 %; 2 µL: ±8 %; 5 µL: ±4 %; 20 µL: ±2 %; 100 µL: ±1 %; 200 µL: ±1 %
- Temperature control block
- Including 2 temperature control blocksTemperature control range: 4~105 °CTemperature control accuracy: ≤1 °CTemperature control uniformity: ≤1 °C @55 °C
- Gene amplification block
- Temperature control range: thermo lid: +30 °C~+120 °C; block: +4 °C~+99 °CUniformity: ≤0.7 °CAccuracy: ≤±0.3 °C
- Fluorescence detection range
- 0.4 ng~100 ng
- Automatic clamping and heating mixing block
- Yes
- Magnetic plate
- 96-well annular magnetic plate
- Gripper
- Including one
- Stacking plate lifting block
- Including one
- UV sterilization
- Equipped with UV sterilization lamp, HEPA device
- Instrument port
- USB port
- Information management
- External scanner for entering sample/reagent informationExpandable LIS system connectionExpandable cloud database connection
- Ambient condition
- Temperature requirement: 20±5 °CRelative humidity: ≤80%
- Power input
- 100~240 V, 50 / 60 Hz, rated power 1200 W
