- Model
- 11224 BBC 86 / 11234 BBC 86 / 11244 BBC 86
- External Size(W*D*H)
- 1087*760*2100mm / 1380*760*2100mm / 1877*760*2100mm
- Internal Size(W*D*H)
- 910*600*630mm / 1220*600*630mm / 1700*600*630mm
- Tested Opening
- Safety height 200mm(8")
- Max Opening
- 440mm(17")
- Inflow Velocity
- 0.53±0.025m/s
- Down Flow Velocity
- 0.33±0.025m/s
- Exhaust Volume
- 347m³/h / 465m³/h / 648m³/h
- Air Supply Filter
- ULPA filter, efficiency>99.9995% for particle size at 0.12μm
- Exhaust Filter
- ULPA filter: first exhaust filter: 0.12μm efficiency 99.9995%HEPA filter: secondary exhaust filter: 0.3μm efficiency 99.995%
- Alarm
- Abnormal airflow velocity, Filter replacement, Front window at unsafe height; High filter pressure alarm
- Noise
- ≤67dB
- Water&Gas Tap
- Water tap*1, Gas tap*1
- UV Lamp
- 20W*1 / 30W*1 / 40W*1
- UV Lamp
- Emission of 253.7 nanometers for most efficient decontaminationUV life indicator, UV timer
- LED Lamp
- 12W*2 / 14W*2 / 16W*2
- Illumination
- ≥1000Lux
- Consumption
- 700W / 900W / 1300W
- Waterproof Socket
- Two, total load of two sockets: ≤500W
- Display
- LCD display
- Control System
- Microprocessor
- Humidity and Temperature
- Humidity and temperature can be displayed on the control panel
- Material
- Work Area: 304 stainless steelMain Body: cold-rolled steel with anti-bacteria powder coating
- Front Window
- Motorized, two-layer laminated toughened glass≥6mm, anti-UV
- Caster
- Footmaster caster
- Power Supply
- AC220V±10%, 50/60Hz; 110V±10%, 60Hz
- Standard Accessory
- Base stand, Drain valve, Waterproof sockets*2, Remote control, LED lamp*2, UV lamp*2, Water tap, Gas tap
- Optional Accessory
- Armrest, Formalin fumigation sterilizer, Infrared sterilizer, Airflow tester
- Gross Weight
- 320kg / 371kg / 430kg
- Package Size(W*D*H)
- 1240*910*2280mm / 1540*910*2280mm / 2050*910*2260mm
