Digital Slide Scanner

Model NSS-6

The Digital Slide Scanner is an advanced imaging system designed for high-resolution scanning of microscope slides, transforming glass slides into digital images for efficient storage, analysis, and sharing.

A tailored quote, without the guesswork.

Ask about availability, configuration and delivery to your location. We reply personally.

Request a quote
Enquiry only. No payment is taken.
  • Specifications confirmed with you before any order
  • International delivery arranged to your facility
  • Personal sourcing support from first message to arrival
A closer look

About this equipment

Features:

1. High-precision scanning slide platform

2. High-speed scanning

3. Clear, bright, and uniform imaging

4. Batch scanning

5. Image management and browsing

Technical Parameters:

Model BKSS-M60
Slide Capacity 1~6pcs
Slide Size Thickness 0.9~1.2mm, size 26*76mm
Objective 20X Plan Apochromat Objective, N.A.=0.75
Scanning Ratio 20X and 40X high-speed scanning
Scan Resolution ≤0.48μm/pixel(20X)

≤0.24μm/pixel(40X)
Scanning Platform Magnetic levitation linear motor, high-precision fully closed-loop drive control system
Scan Speed Tissue area 15mmx15mm, 20x scanning time ≤40 seconds
Repeatability 0.1μm
Focus Mode Fully automatic focus, automatic search for scanning samples, can also be set manually
Scanning Method Bright field scanning
Viewable Range 1.3mm
Illumination System LED professional light source, compound eye lens technology
Software Software for image scanning, management and viewing
Power Supply 220V, 50/60Hz; 110V, 56/60Hz
Packing Size 1000*1000*740mm
Gross Weight 72kg
The details

Specifications

Model
BKSS-M60
Slide Capacity
1~6pcs
Slide Size
Thickness 0.9~1.2mm, size 26*76mm
Objective
20X Plan Apochromat Objective, N.A.=0.75
Scanning Ratio
20X and 40X high-speed scanning
Scan Resolution
≤0.48μm/pixel(20X)≤0.24μm/pixel(40X)
Scanning Platform
Magnetic levitation linear motor, high-precision fully closed-loop drive control system
Scan Speed
Tissue area 15mmx15mm, 20x scanning time ≤40 seconds
Repeatability
0.1μm
Focus Mode
Fully automatic focus, automatic search for scanning samples, can also be set manually
Scanning Method
Bright field scanning
Viewable Range
1.3mm
Illumination System
LED professional light source, compound eye lens technology
Software
Software for image scanning, management and viewing
Power Supply
220V, 50/60Hz; 110V, 56/60Hz
Packing Size
1000*1000*740mm
Gross Weight
72kg
