Horizontal Planetary Ball Mill

Model

Capacity

2L

Volume of Each Capacity

50~500ml

Pot Quantity

4pcs

Running Time Range

1~9999min

Reciprocal Running Time

1~999min

Adjustable Speed Revolution

35~335rpm

70~670rpm

Noise

60±5dB

Transmission Mode

Gear drive

Working Mode

2 or 4 pots can be used each time

Maximum Sample Volume(material+grinding ball)

2/3 of the volume of the ball mill tank

Feed Size

Soft and crispy material<10mm, Other materials<3mm

Out-put Granularity

Minimum Granularity can be reached to 100nm

Adjusting Mode of Rotate Speed

Frequency converter with stepless speed regulation

Speed Control Mode

Frequency control

Consumption

Power Supply

AC 220V, 50/60Hz(Standard); 110V, 50/60Hz(Optional)

External Size(W*D*H)

Package Size(W*D*H)

Net Weight

Gross Weight

Note: Both pot and ball are optional. For a ball mill with a capacity of 2L, if the matching mill pot specification is 25ml or 50ml, you need to purchase a base holder separately.
