Ion Chromatograph BK-IC260D

Model BK-IC260D Compact & portable

The Ion Chromatograph BK-IC260D is a compact, dual-channel ion analysis system capable of simultaneous anion and cation detection. It features an intelligent alarm system with leakage, residual eluent, low-pressure, and high-pressure alerts, along with real-time consumables monitoring for clear operational status. Its space-saving design enhances laboratory space utilization while delivering reliable, high-sensitivity analytical performance.

A tailored quote, without the guesswork.

Ask about availability, configuration and delivery to your location. We reply personally.

Request a quote
Enquiry only. No payment is taken.
  • Specifications confirmed with you before any order
  • International delivery arranged to your facility
  • Personal sourcing support from first message to arrival
A closer look

About this equipment

Features:

1. Dual channel design, allows for simultaneous detection of anions and cations.

2. Intelligent alarm system. Leakage alarm, residual eluent alarm, low pressure alarm and high-pressure alarm.

3. Real time monitoring of consumables usage, with clear status at a glance.

4. The compact exterior design can improve the space utilization rate of the laboratory.

Technical Parameters:

Model

BK-IC260D
Detected Ions

Anions and cations

Pump

 Type High-pressure and low-pulse two-piston tandem advection pump
Maximum Pressure 42MPa
Flow Rate Range 0.001~12mL/min
Pressure Ripple ≤0.5%
Flow Precision ≤0.1%

Column Oven

 Operating Temperature Range RT+5~85℃
Controlling Temperature Accuracy ±0.1℃
Temperature Stability ≤0.1℃/h
Columns Supported 2, 3, 4 and 5mm ID.

Maximum length 250mm analytical column with 50mm guard column.

Conductivity Detector

 Type Auto-range conductivity detector
Cell Volume ≤0.4μL
Detection Range 0~50000μS/cm
Resolution ≤0.0020nS/cm
Operating Temperature Range RT+5℃~60℃
Maximum Pressure 10.0MPa

Suppressor

 Type Self-regeneration electrolytic micromembrane suppressor
Maximum Pressure 6.0MPa
Non-suppressed Chromatography Yes
Void Volume <40μL (4mm)

<15μL (2mm)
Optional Accessories

BK-CIC3200 Fully automatic combustion system, SHA-18i(Double-channel, 120 sample positions) autosampler
Power Supply

AC100~220V 50/60Hz
External Size(W*D*H)

422*500*641mm
Net Weight

42kg
Packing Size(W*D*H)

670*570*790mm; 660*620*400mm
Gross Weight

60kg; 10kg
The details

Specifications

Ask our team for the full specification sheet for this model.

How ordering works

From enquiry to delivery

  1. 01Send your enquiry

    Request a quote on WhatsApp, or add several items to your enquiry list and send them together.

  2. 02Confirm the details

    We confirm configuration, voltage, accessories, availability and a delivered price.

  3. 03We source and ship

    We handle procurement, packing and international shipping to your facility.

Need a different configuration?

Tell us the application, capacity or budget. We will suggest the right model or source an alternative.
