Shaking Incubator

Stacked Large Capacity Shaking Incubator(BJPX-SDT)

Model BJPX-SDT10 BJPX-SDT20 Large capacity Refrigerated

The Stacked Large Capacity Shaking Incubator is a high-performance device designed for large-scale cell culture, microbial fermentation, and other temperature-sensitive shaking applications. With its stacked design, this incubator maximizes space efficiency in laboratories while offering increased capacity for simultaneous experiments.

Max. speed
300 rpm
Capacity
80L
Temperature
RT+5~60℃ / 4~60℃
Power
1000W / 1600W
Net weight
138kg / 158kg
Dimensions
580*830*600mm
A tailored quote, without the guesswork.

Ask about availability, configuration and delivery to your location. We reply personally.

Request a quote
Enquiry only. No payment is taken.
  • Specifications confirmed with you before any order
  • International delivery arranged to your facility
  • Personal sourcing support from first message to arrival
A closer look

About this equipment

Features:

1. Brushless DC motor, low noise, lasting operation.

2. 5″ touch screen, clear and intuitive interface.

3. Run parameter encryption lock, parameter memory function.

4. With power failure recovery function.

5. Motor overheat, temperature control, abnormal over temperature instrument automatically cut off their power supply.

6. With USB data export function to achieve data traceability.

7. With ultraviolet disinfection function.

8. Standard equipped with LED light, open the door of the box light automatically open.

Technical Parameters:

Model BJPX-SDT10 BJPX-SDT20
Capacity

80L
Temp. Sensor

PT100
Temp. Range RT+5~60℃ 4~60℃
Temp. Fluctuation

≤±0.5℃
Temp. Uniformity

≤±1℃(37℃）
Temp. Precision

0.1℃
Timing Range

0~999min
Controller

PID
Display

5-inch touch screen
Circulation Mode

Forced convection
Shaking Mode

Rotary shaking
Drive Mode

Single axis balanced drive type
Vibration Range

Φ26mm
Rotating Speed

30~300r/min
Rotating Accuracy

±1r/min
Shaking Plate Size

420*400mm
Shaking Plate Quantity

1pc
Max. Capacity

250ml*16 or 500ml*9 or 1000ml*9 or 2000ml*5(Flask clamp)

Tube rack*2

96-well plate*8

Clamping rod shaking plate*1
Standard. Capacity

500ml*9
Lighting Mode

LED lamp*1
Sterilization Mode

UV lamp*1
Refrigerant / R290, 70g
Ambient Temp.

15~35℃
Internal Material

304 stainless steel
External Material

Cold rolled steel sheet
Safety Function

High/low temperature, abnormal shutdown, motor failure, equipment door is not closed properly automatic alarm, alarm mode is sound and light alarm
Consumption 1000W 1600W
Power Supply

AC220V, 50/60Hz(Standard); 110V, 50/60Hz(Optional, external transformer)
Internal Size(W*D*H)

495*455*370mm(Per unit)
External Size(W*D*H)

580*830*600mm(Per unit)
Package Size(W*D*H)

705*975*865mm(Per unit)
Net Weight 138kg(Per unit) 158kg(Per unit)
Gross Weight 168kg(Per unit) 188kg(Per unit)
The details

Specifications

Model
BJPX-SDT10 / BJPX-SDT20
Capacity
80L
Temp. Sensor
PT100
Temp. Range
RT+5~60℃ / 4~60℃
Temp. Fluctuation
≤±0.5℃
Temp. Uniformity
≤±1℃(37℃）
Temp. Precision
0.1℃
Timing Range
0~999min
Controller
PID
Display
5-inch touch screen
Circulation Mode
Forced convection
Shaking Mode
Rotary shaking
Drive Mode
Single axis balanced drive type
Vibration Range
Φ26mm
Rotating Speed
30~300r/min
Rotating Accuracy
±1r/min
Shaking Plate Size
420*400mm
Shaking Plate Quantity
1pc
Max. Capacity
250ml*16 or 500ml*9 or 1000ml*9 or 2000ml*5(Flask clamp)Tube rack*296-well plate*8Clamping rod shaking plate*1
Standard. Capacity
500ml*9
Lighting Mode
LED lamp*1
Sterilization Mode
UV lamp*1
Refrigerant
/ / R290, 70g
Ambient Temp.
15~35℃
Internal Material
304 stainless steel
External Material
Cold rolled steel sheet
Safety Function
High/low temperature, abnormal shutdown, motor failure, equipment door is not closed properly automatic alarm, alarm mode is sound and light alarm
Consumption
1000W / 1600W
Power Supply
AC220V, 50/60Hz(Standard); 110V, 50/60Hz(Optional, external transformer)
Internal Size(W*D*H)
495*455*370mm(Per unit)
External Size(W*D*H)
580*830*600mm(Per unit)
Package Size(W*D*H)
705*975*865mm(Per unit)
Net Weight
138kg(Per unit) / 158kg(Per unit)
Gross Weight
168kg(Per unit) / 188kg(Per unit)
