Application: Widely used in the field such as biology, chemistry, microbiology, physics, zoology, agronomy, medical science for teaching, scientific research and production.
Ask about availability, configuration and delivery to your location. We reply personally.
Enquiry only. No payment is taken.Features:
1. LCD touch screen display.
2. Storage capacity: 20 groups of program data.
3. Temp. monitor: over-temperature protection.
4. Other functions: automatic tracking the frequency, fault alarm.
Technical Parameters:
| Model | UCD-150 | UCD-250 | UCD-500 | UCD-650 | UCD-950 | UCD-1200 | UCD-1500 | UCD-1800 | UCD-2000 |
| Frequency(KHz) | 20~25 | 20~25 | 20~25 | 20~25 | 20~25 | 19.5~20.5 | 19.5~20.5 | 19.5~20.5 | 19.5~20.5 |
| Crushing Capacity(ml) | 0.1~150 | 0.1~300 | 0.1~400 | 0.1~500 | 0.1~700 | 1~1000 | 10~1200 | 1~1200 | 50~2000 |
| Standard Amplitude-change PoleΦ(mm) |
6 |
20 | 22 | 22 | 25 | ||||
| Optional Amplitude-change Pole Φ(mm) | 2, 3, 6, 8,10 | 2, 3, 6, 8, 10 | 2, 3, 6, 8, 10, 12 | 2, 3, 6, 8, 10, 12 | 2, 3, 6, 8, 10, 12, 15 | 3, 6, 8，10, 15, 22, 25 | 3, 6, 8，
10, 15, 20, 22, 25 |
3, 6, 8，
10, 15, 20, 22, 25 |
6, 8, 10, 15, 20, 22
, 25 |
| Ultrasonic Power(W1-100%) | 1.5~150 | 2.5~250 | 5~500 | 6.5~650 | 10~1000 | 12~1200 | 15~1500 | 18~1800 | 20~2000 |
| Power Supply |
AC220V, 50/60Hz(Standard); AC110V, 50/60Hz(Optional) |
||||||||
| Package Size(W*D*H) |
350*350*550mm(Acoustic chamber) 470*305*450mm(Main body) |
||||||||
| Gross Weight |
26kg |
29kg |
|||||||
Technical Parameter for Amplitude Pole:
| Size | Crushing Capacity |
Recommended Power Ratio |
Frequency(KHz) | UCD-150 | UCD-250 | UCD-500 | UCD-650 | UCD-950 | UCD-1000 | UCD-1200 | UCD-1500 | UCD-1800 | UCD-2000 |
| φ2mm | 0.1~5ml | 1~35% | 20~25 | √ | √ | √ | √ | √ | √ | x | x | x | x |
| φ3mm | 3~10ml | 1~45% | 20~25 | √ | √ | √ | √ | √ | √ | √ | √ | √ | x |
| φ5mm | 5~100ml | 1~60% | 20~25 | x | x | x | x | x | x | x | x | x | x |
| φ6mm | 10~100ml | 1~70% | 20~25 | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ |
| φ8mm | 20~200ml | 1~85% | 20~25 | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ |
| φ10mm | 30~300ml | 1~90% | 20~25 | v | √ | √ | √ | √ | √ | x | x | x | x |
| φ10mm | 30~300ml | 1~60% | 19.5~20.5 | x | x | x | x | x | x | √ | √ | √ | √ |
| φ12mm | 50~600ml | 10~90% | 20~25 | x | x | √ | √ | √ | √ | x | x | x | x |
| φ15mm | 200~750ml | 10~95% | 20~25 | x | x | x | x | √ | √ | x | x | x | x |
| φ15mm | 50~500ml | 5~80% | 19.5~20.5 | x | x | x | x | x | x | √ | √ | √ | √ |
| φ20mm | 100~1000ml | 10~90% | 19.5~20.5 | x | x | x | x | x | x | √ | √ | √ | √ |
| φ22mm | 200~1200ml | 20~95% | 19.5~20.5 | x | x | x | x | x | x | √ | √ | √ | √ |
| φ25mm | 300~1500ml | 30~95% | 19.5~20.5 | x | x | x | x | x | x | √ | √ | √ | √ |
Request a quote on WhatsApp, or add several items to your enquiry list and send them together.
We confirm configuration, voltage, accessories, availability and a delivered price.
We handle procurement, packing and international shipping to your facility.
