- Model
- BDF-40H110 / BDF-40H210 / BDF-40H310 / BDF-40H485
- Capacity
- 110L / 210L / 308L / 485L
- Temp. Range
- -15~-40℃ / -20~-40℃ / -20~-40℃ / -20~-40℃
- Temp. Accuracy
- 0.1℃
- Temp. Uniformity
- ≤3℃
- Temp. Stability
- ≤3℃
- Recovery Time(Recover to -37℃ in an ambient temp. of 25℃)
- ≤5min
- Cooling Time(Cool down to -40℃ in an ambient temp. of 25℃)
- ≤150min / ≤195min / ≤195min / ≤195min
- Control System
- Microprocessor control
- Display
- LED display
- Alarm
- High/low temperature alarm, power failure alarm(72h), controller failure alarm / High/low temperature alarm, power failure alarm(8h), controller failure alarm / High/low temperature alarm, power failure alarm(8h), controller failure alarm / High/low temperature alarm, power failure alarm(8h), controller failure alarm
- Refrigeration Type
- Direct-cooling
- Refrigerant
- R290/50g / R290/55g / R290/60g / R290/68g
- Compressor
- International famous brand compressor /1
- Condenser & Evaporator
- Wire-on-tube Bundy tube condenser; built-in coil type copper tube evaporator
- Defrost
- Manual defrost
- Construction
- Polyurethane cyclopentane foam
- Material
- Internal Material / 304 stainless steel / 304 stainless steel / 304 stainless steel
- Material
- External Material / Sprayed steel plate / Sprayed steel plate / Sprayed steel plate
- Door
- Outer door: cyclopentane integral foam outer door*1Inner door: /
- Consumption
- 270W / 280W / 290W / 300W
- Power Supply
- AC 220V, 50Hz(Standard); 110/220V, 60Hz(Optional, external transformer) / AC 220V, 50/60Hz(Standard); 110V, 50/60Hz(Optional, external transformer) / AC 220V, 50/60Hz(Standard); 110V, 50/60Hz(Optional, external transformer) / AC 220V, 50/60Hz(Standard); 110V, 50/60Hz(Optional, external transformer)
- Casters
- Yes
- Shelf
- /
- Standard Accessory
- Test hole
- Optional Accessory
- Temperature recorder, RS485 interface, USB interface / Temperature recorder / Temperature recorder / Temperature recorder
- Internal Size (W*D*H)
- 520*460*600mm / 760*540*600mm / 1038*540*600mm / 1455*525*665mm
- External Size (W*D*H)
- 705*705*885mm / 945*785*885mm / 1225*790*885mm / 1667*863*949mm
- Package Size (W*D*H)
- 805*800*1015mm / 1045*880*1015mm / 1325*885*1015mm / 1775*900*1050mm
- Net Weight
- 58kg / 68kg / 76kg / 124kg
- Gross Weight
- 73kg / 88kg / 101kg / 138kg
