- Model
- BDF-40V58 / BDF-40V90 / BDF-40V208 / BDF-40V268
- Capacity
- 58L / 90L / 208L / 268L
- Temp. Range
- -15~-40℃
- Temp. Accuracy
- 0.1℃
- Temp. Uniformity
- ≤4℃
- Temp. Stability
- ≤4℃
- Recovery Time(Recover to -37℃ in an ambient temp. of 25℃)
- 40min / ≤15min / ≤30min / ≤30min
- Cooling Time(Cool down to -40℃ in an ambient temp. of 25℃)
- 50min / ≤1.5h / ≤4h / ≤4h
- Control System
- Microprocessor control
- Display
- LED
- Alarm
- High/low temperature alarm, controller failure alarm / High/low temperature alarm, power failure alarm(8h), controller failure alarm, door ajar alarm / High/low temperature alarm, power failure alarm(8h), controller failure alarm, door ajar alarm / High/low temperature alarm, power failure alarm(8h), controller failure alarm, door ajar alarm
- Refrigeration Type
- Direct-cooling
- Refrigerant
- R290/70g / R290/43g / R290/75g / R290/75g
- Compressor
- International famous brand compressor/1
- Condenser&Evaporator
- Finned copper tube condenser; built-in coil type copper tube evaporator / Wire-on-tube Bundy tube condenser; built-in coil type copper tube evaporator / Wire-on-tube Bundy tube condenser; built-in coil type copper tube evaporator / Wire-on-tube Bundy tube condenser; built-in coil type copper tube evaporator
- Defrost
- Manual defrost
- Construction
- Polyurethane cyclopentane foam
- Material
- Internal Material / 304 stainless steel / 304 stainless steel / 304 stainless steel
- Material
- External Material / Sprayed steel plate / Sprayed steel plate / Sprayed steel plate
- Door
- Outer door: sprayed steel plate outer door*1Interior door: 304 stainless steel door*1 / Outer door: sprayed steel plate outer door*1Interior door: cold plate spray door*3 / Outer door: sprayed steel plate outer door*1Interior door: cold plate spray door*4 / Outer door: sprayed steel plate outer door*1Interior door: cold plate spray door*4
- Consumption
- 290W / 252W / 284W / 286W
- Power Supply
- AC220V, 50Hz(Standard); 110/220V, 60Hz(Optional) / AC220V. 50Hz(Standard);220V, 60Hz, 110V, 60Hz(Optional, external transformer / AC220V, 50Hz(Standard); 110/220V, 60Hz(Optional, external transformer) / AC220V, 50Hz(Standard); 110/220V, 60Hz(Optional)
- Casters
- Yes
- Shelf
- 1 / 2 / 3 / 3
- Standard Accessory
- Test hole, USB interface
- Optional Accessory
- Temperature recorder, RS485 / Temperature recorder, RS485, printer / Temperature recorder, RS485, printer / Temperature recorder, RS485, printer
- Internal Size(W*D*H)
- 364*405*410mm / 440*447*640mm / 520*453*1013mm / 520*567*1013mm
- External Size(W*D*H)
- 540*620*1115mm / 600*610*945mm / 690*630*1631mm / 690*744*1631mm
- Package Size(W*D*H)
- 670*760*1290mm / 730*730*1140mm / 840*750*1810mm / 810*860*1820mm
- Net Weight
- 78kg / 63kg / 112kg / 115kg
- Gross Weight
- 98kg / 82kg / 133kg / 140kg
