- Model
- FIM20 / FIM30 / FIM40 / FIM50 / FIM60 / FIM70 / FIM85 / FIM100 / FIM120 / FIM150 / FIM200 / FIM250
- Ice Making Capacity(kg/24h)
- 20 / 30 / 40 / 50 / 60 / 70 / 85 / 100 / 120 / 150 / 200 / 250
- Max. Ice Storage Capacity
- 10kg / 15kg / 25kg / 40kg / 60kg / 60kg / 60kg / 60kg / 60kg / 60kg / 60kg / 60kg
- Ice Shape
- Small particle of irregular snow ice
- Input Current
- 280W / 300W / 360W / 380W / 420W / 460W / 480W / 520W / 550W / 680W / 1040W / 1100W
- Way of Condensation
- Air cooling
- Ambient Temperature
- 10~35℃
- Water Temperature
- 2~15℃
- Tank Shell
- Stainless steel
- Compressor
- Donper / Panasonic Wanbao / Donper / Panasonic Wanbao / Panasonic Wanbao / Panasonic Wanbao / Panasonic Wanbao / Panasonic Wanbao / Panasonic Wanbao / Panasonic Wanbao / Panasonic Wanbao / Panasonic Wanbao
- Refrigerant
- R290, 30g / R290, 35g / R290, 42g / R290, 55g / R290, 62g / R290, 65g / R290, 140g / R290, 140g / R290, 140g / R290, 140g / R290, 140g / R290, 140g
- Standard Accessory
- Water inlet pipe*1, drainage pipe*1, ice spoon*1
- Optional Accessory
- Filter
- Power Supply
- AC220V, 50/60Hz(Standard); 110V, 60Hz(Optional)
- External Size(W*D*H)
- 330*470*605mm / 400*543*700mm / 400*510*845mm / 500*611*950mm / 680*740*1100mm / 680*740*1100mm / 680*740*1100mm / 680*740*1100mm / 680*740*1100mm / 680*740*1100mm / 680*740*1100mm / 680*740*1100mm
- Package Size(W*D*H)
- 460*595*740mm / 520*665*845mm / 520*630*995mm / 630*730*1110mm / 730*800*1270mm / 730*800*1270mm / 730*800*1270mm / 730*800*1270mm / 730*800*1270mm / 730*800*1270mm / 730*800*1270mm / 730*800*1270mm
- Net Weight
- 26kg / 36kg / 42kg / 58kg / 60kg / 80kg / 80kg / 80kg / 80kg / 80kg / 80kg / 80kg
- Gross Weight
- 42kg / 55kg / 62kg / 82kg / 105kg / 105kg / 105kg / 105kg / 105kg / 105kg / 105kg / 105kg
- Applicable Area
- Various types of experiments, hospitals, schools, laboratories, medical, chemical applications, supermarkets, hotels and other seafood products stores etc.
