It is used to quantitatively analyze the clinical chemistry of human serum, plasma, urine, cerebrospinal fluid and other samples. Do not use for other purposes.
Ask about availability, configuration and delivery to your location. We reply personally.
Enquiry only. No payment is taken.Features:
1. 600 tests per hour.
2. 120 reaction cuvettes.
3. 180 refrigerated reagent positions.
4. Built-insample barcode system optional.
5. 90 sample positions(120 sample positions optional).
6. Probe with anti-collision function, liquid level detection function.
Technical Parameters:
| Model |
BK-600 |
|
|
Overall Performance |
Throughput | 600 tests/hour |
| Analysis Method | End-point, Fixed-time, Rate(Kinetic), Turbidimetry | |
| Certification | CE, FDA, ISO9001, ISO13485 | |
|
Sample&Reagent System |
Sample Positions | 90 sample positions, built-in barcode system available |
| Reagent Positions | 180 refrigerated reagent positions(R1: 90&R2: 90) | |
| Sample Volume | 1~70μl | |
| Reagent Volume | 10~350μl | |
| Probe |
Teflon coating, with anti-colision function, liquid level detection function |
|
| Probe Washing | Automatic washing interior and exterior | |
| Reagent Cooling | 2~8℃ | |
|
Reaction System |
Temperature Control | 37±0.1℃, real-time monitoring |
| Cuvettes | 120 reusable cuvettes, optical length 6mm | |
| Mixer Probe | Independent stirring | |
| Washing | Automatic cuvettes washing | |
| STAT Function | YES | |
|
Optical System |
Light Source | 12V/20W halogen lamp |
| Spectrophotometry | Post-spectral spectrophotometry | |
| Wavelength | 340~ 800nm | |
| Absorbance | 0~3.5Abs | |
|
Calibration&QC |
Calibration | 1-point, 2-point and multipoint, factor, Spline, Logit-4P, Logit-5P, Polygon |
| Quality Control | Inserting quality control at random | |
|
Data Management |
Software | Windows 7/8/10 |
| LIS System | Available | |
| Interface | TCP/IP network interface | |
| Printer | External optional, multiple reporting mode available | |
|
Working Conditions |
Power Supply | AC220V±10%, 50/60Hz; 110V±10%, 60Hz, 800VA |
| Temperature | 15~30℃ | |
| Water Consumption | Deionized water: 20L/H | |
| Humidity | 40%~85% | |
|
Size&Weight |
External Size(W*D*H) | 1170*775*1145mm |
| Net Weight | 216kg | |
| Package Size(W*D*H) | 1358*938*1387mm | |
| Gross Weight | 281kg | |
| Accessory Package Size | 550*430*860mm | |
| Accessory Gross Weight | 20kg | |
Ask our team for the full specification sheet for this model.
Request a quote on WhatsApp, or add several items to your enquiry list and send them together.
We confirm configuration, voltage, accessories, availability and a delivered price.
We handle procurement, packing and international shipping to your facility.
