- Throughput
- 1-96
- Speed
- Daily inspection volume ≥ 6000 tubes
- Adding Sample
- 2-1000ul
- Temperature Accuracy
- ±0.3℃
- Temperature Uniformity
- ±0.3℃
- Module Temperature Range
- 4-100℃
- Sample Volume
- 10-50ul
- Fluorescence Channel
- 4 channels, FM , VIC , ROX , Cy5
- Machine Function
- Putting the original tube on the machine + sample splitting + nucleic acid extraction + R C R system construction + amplification detection
- Sample Loading Method
- Flow loading, single sample volume 96
- Consumables Added
- Flowing consumables, running without stopping
- Liquid Detection Scheme
- Pneumatic liquid level detection scheme, intelligent detection of blocked needle
- Sample Needle Specifications
- 50μl, 200μl, 1000μl optional, disposable black conductive needle with filter
- Sampling Tube Adaptation
- Suitable for conventional 5mL, 10mL, 20/30mL virus sampling tubes
- Protective Function
- Power-on self-test, high temperature alarm, over-temperature protection, needle removal and needle removal protection
- Disinfection &Decontamination Methods
- UV lamp (cup compartment + extraction compartment + extraction area + sealing compartment + testing compartment), multi-directional disinfection
- Touch Screen
- Four 10.1-inch capacitive touch screens
- External Size
- 6300*750*1900mm
