Enquiry only. No payment is taken.Features：
• Open system – compatible with all standard IV sets.
• Large COLOR TFT display with adjustable brightness.
• Manual/Automatic Bolus.
• Anti-bolus system.
• DPS dynamic pressure display.
• 2000 events stored can be checked and downloaded.
• Five work modes: Rate Mode, Time Mode, Dose Mode, Sequential Mode and Drug
Library Mode.
• Drug library with 1030 drug names (Optional).
•8 Hours Internal Battery continuous operation.
• Visual and audible Alarm system and accurate infusion rate for safety and reliability.
• Very accurate and reliable.
• Friendly user interface.
• Dynamically display working status.
• KVO and Bolus functions.
• Automatically record the setting of last infusion.
• Preset Solution Volume for nurse workload reduction.
•Change the flow rate without stop during infusion
• Three levels of the occlusion: high, middle, and low.
• Easy to clean through the open door design.
Technical Specifications：
| Model | DPfusion VP1 | DPfusion VP3 |
| Fit IV Tubes |
Can be used with any brand IV set after exactly calibration |
|
| Pump Type |
Peristaltic fingerpump |
|
| Accuracy |
±2% |
|
| Delivery Rate Range |
0.1ml/h～1200ml/h (0.1ml/h～99.9ml/h, 0.1ml/h step; >99.9ml/h, 1ml/h step) |
|
| Delivery Time Range |
00h01min～99h59min (1 min step) |
|
| Volume Limit Range |
0.0-9999ml (1 ml step) |
|
| Total Volume Range |
0.0-9999ml (1 ml step) |
|
| Purge Rate |
600.0ml/h(Adjustable) |
|
| KVO Rate |
0.1~5.0ml/h. Programmable and adjustable |
|
| Occlusion Pressure |
LOW：60（±15）kPa, MEDIUM: 90（±15）kPa or HIGH: 120（±15）kPa(Programmable and adjustable) |
|
| Alarms |
Rate Abnormal，Door Open，Air-in-Line，Occlusion，Bottle Empty，Battery Empty，No Battery，Key Holding During Infusion/ Pause，Infusion Complete，No Action，Battery Low Three levels of alarm volume LOW, MEDIUM or HIGH |
|
| Dose Mode |
Volume：0.1-999.9ml(0.1ml step)DRUG MASS：0.1-999.9mg 0.1mg step)DOSE：0.001-9999ug/kg/min(0.001ug/kg/min step)WEIGHT：0.1-300kg(0.1kg the least step) Dose unit: ng/kg/min, ug/kg/min, mg/kg/min, g/kg/min, ug/kg/h,mg/kg/h, g/kg/h,ug/min,mg/min,g/min,ug/h,mg/h,g/h,U/min,U/h,IU/h,U/kg/h,ml/h |
|
| Bolus Function |
Bolus rate:1.0~1200ml/h,Bolus volume:1.0~100ml Programmable and adjustable, Automatic/Manual bolus available |
|
| Drug Library Mode |
10 categories of drugs, amounts to 1030 kinds of drug names, 17kinds of dose units, such as ug/kg/min, mg/kg/min,etc. Makes drug dispensing more convenient and safer.(Optional) (Only for VP3) |
|
| Sequential Mode |
/ |
|
| Interface |
RS-232 |
|
| Brightness |
1~10 levels can be selected |
|
| History Records |
2000 events stored can bechecked and downloaded |
|
| Power Supply |
AC power supply: AC 100 to 240V( +/-10%)，50/60Hz; DC Power supply: 12~15V, power>15W; Built-in Lithium Battery: Rechargeable, 11.1V, 2000mAh. 8 hours of continuous operation |
|
| Accessories: |
AC power line, Operational manual |
|
| Protection Class |
Class I, Type CF,IPX4 |
|
| Dimension |
215*100*120mm |
|
| N.W |
1.7kg |
|
| Packing Size |
250*190*155mm |
|
| G.W |
2.5KG |
|
