Nucleic Acid Extractor

Nucleic Acid Fragment Analyzer

Model BK-NAF96 Microplate & PCR

BKC-MPC2800 Centrifuge for Microplates is designed for quick spins of samples in PCR plates. Prirarily designed for use with 96 or 384 well plates and small volumes, it will accommodate skirted, non skirted and semi skirted styles.

Power
500 VA
Net weight
25 kg
Dimensions
590 mmx420 mmx500 mm
A tailored quote, without the guesswork.

Ask about availability, configuration and delivery to your location. We reply personally.

Request a quote
Enquiry only. No payment is taken.
  • Specifications confirmed with you before any order
  • International delivery arranged to your facility
  • Personal sourcing support from first message to arrival
A closer look

About this equipment

Ⅰ Fragment Analysis Expert
BKC-MPC2800 Centrifuge for Microplates is designed for quick spins of samples in PCR plates. Primarily designed for usewith 96 or 384 well plates and small volumes, it will accommodate skirted, non skirted and semi skirted styles

1. Convenient

No gel preparation required; pre-packaged, pre-cast gel chips

One-click operation without complex parameter settings

A streamlined, minimal-effort preprocessing workflow

2. Fast

16 samples analyzed in 8 minutes

96 samples analyzed in 45 minutes

3. Flexible

No need to batch samples; compatible with 1 to 96 samples per run

Reduced waste through on-demand lane activation

Customizable analysis results

4. Precise

Independent sample loading to prevent cross-contamination

High detection sensitivity for pg-level DNA/RNA analysis

Ⅱ Reagents Parameter

Reagent Type Adaptable Sizing Range Sensitivity Quanitification Range Sample Loading Integrity Sample Scalability Chips
DNA 1K

35-1,000 bp dsDNA fragment

 0.1 ng/μL 0.1 -50 ng/μL 1μL

–

1-16

6
High Sensitivity DNA 1K 5 pg/μL 10-1,000 pg/μL 2μL
DNA 5K

100-5,000 bp dsDNA fragment

 0.1 ng/μL 0.1-50 ng/μL 1μL
High Sensitivity DNA 5K 5 pg/μL 10-1,000 pg/μL 2μL
Genomic DNA

200-60,000+ bp dsDNA fragment

 0.5 ng/μL 10-100 ng/μL 1μL

√
High Sensitivity Genomic DNA 20 pg/μL 0.5-10 ng/μL 2μL
cfDNA 50-800 bp ds DNA fragment 20 pg/μL 100-4,000 pg/μL 2μL –
RNA

Eukaryotic/ProkaryoticTotal RNA

 5 ng/μL 25-500 ng/μL 1μL

√
High Sensitivity RNA 100 pg/μL 500-10,000 pg/μL 2μL

Ordering Information

PN Product
M000047 Fragment Analyzer-BK-NAF96
M000058 DNA 1K Fragment Analysis Reagent Kit
M000059 DNA 5K Fragment Analysis Reagent Kit
M000060 High Sensitivity DNA 1K Fragment Analysis Reagent Kit
M000061 High Sensitivity DNA 5K Fragment Analysis Reagent Kit
M000062 Genomic DNA Fragment Analysis Reagent Kit
M000063 High Sensitivity Genomic DNA Fragment Analysis Reagent Kit
M000064 cfDNA Fragment Analysis Reagent Kit
M000065 RNA Fragment Analysis Reagent Kit
M000066 High Sensitivity RNA Fragment Analysis Reagent Kit

System Specification

Dimensions (W XD X H) 590 mmx420 mmx500 mm
Net Weight 25 kg
Power 500 VA
Power Requirements AC 100~240 V,50/60 Hz
Operating Environment Temperature:-10°C~50°C

Relative humidity: 15%-85%(non-condensing)

Altitude: below 3000 meter
Computer Configuration CPU: 15-13500H 2.6GHz

Memory:16 GB

Hard disk: 500 GB

Operating system: Microsoft Windows 11

Disclaimer

This document is based on company data of October, 2025, and is provided for reference only.

The availability of products and related data may vary depending on applicable laws, regulations, intellectual proper-ty considerations, and market access requirements in different countries or regions, and may change over time. For confirmation of availability in a particular market, please contact  or its authorized local distributor.

This document does not constitute any offer, commitment, or warranty.

The details

Specifications

PN
Product
M000047
Fragment Analyzer-BK-NAF96
M000058
DNA 1K Fragment Analysis Reagent Kit
M000059
DNA 5K Fragment Analysis Reagent Kit
M000060
High Sensitivity DNA 1K Fragment Analysis Reagent Kit
M000061
High Sensitivity DNA 5K Fragment Analysis Reagent Kit
M000062
Genomic DNA Fragment Analysis Reagent Kit
M000063
High Sensitivity Genomic DNA Fragment Analysis Reagent Kit
M000064
cfDNA Fragment Analysis Reagent Kit
M000065
RNA Fragment Analysis Reagent Kit
M000066
High Sensitivity RNA Fragment Analysis Reagent Kit
Dimensions (W XD X H)
590 mmx420 mmx500 mm
Net Weight
25 kg
Power
500 VA
Power Requirements
AC 100~240 V,50/60 Hz
Operating Environment
Temperature:-10°C~50°CRelative humidity: 15%-85%(non-condensing)Altitude: below 3000 meter
Computer Configuration
CPU: 15-13500H 2.6GHzMemory:16 GBHard disk: 500 GBOperating system: Microsoft Windows 11
