- Model
- RE-2000A / RE-2000B / RE-2000E / RE-52A / RE-52C / RE-5299
- Rotary Bottle
- 1L 24#(Standard size)
- Collecting Bottle
- 1L 35#(Ball mill mouth) / 0.5L 24#(Standard size) / 0.5L 24#(Standard size) / 0.5L 24#(Standard size) / 0.5L 24#(Standard size) / 0.5L 24#(Standard size)
- Condenser
- Vertical φ85*430mm / Vertical φ85*450mm, 29#(Standard size) / Vertical φ85*450mm, 29#(Standard size) / Vertical φ85*450mm, 29#(Standard size) / Vertical φ85*450mm, 29#(Standard size) / Vertical φ85*450mm, 29#(Standard size)
- Charging Valve
- 19#(Standard size)
- Rotating Speed
- 0~200rpm / 0~120rpm / 0~120rpm / 0~120rpm / 0~120rpm / 0~120rpm
- Vacuum
- -0.098Mpa
- Temp. Range
- RT~99℃
- Temp. Accuracy
- ±1℃
- Stroke Height
- 120mm / 150mm / 150mm / 150mm / 150mm / 150mm
- Rotating Power
- 40W / 30W / 30W / 30W / 30W / 30W
- Heating Power
- 1.5KW / 1KW / 1KW / 1KW / 1KW / 1KW
- Shelf Material
- Aluminum alloy / Powder coating anticorrosive / Powder coating anticorrosive / Powder coating anticorrosive / Powder coating anticorrosive / Powder coating anticorrosive
- Chamber Size
- φ235*145mm / φ220*120mm / φ245*140mm / φ245*140mm / φ245*140mm / φ245*140mm
- Power Supply
- Standard: AC220V, 50/60Hz; Optional: AC110V, 60Hz
- External Size(W*D*H)
- 630*400*690~810mm / 640*430*860~1010mm / 660*440*880~1030mm / 660*440*880~1030mm / 660*440*880~1030mm / 660*440*880~1030mm
- Package Size(W*D*H)
- 620*620*490mm / 600*460*470mm / 600*460*470mm / 600*460*470mm / 600*460*470mm / 600*460*470mm
- Gross Weight
- 25kg / 23kg / 19kg / 20kg / 20kg / 20kg
- Standard Accessory
- 1000ml rotary bottle*1, 500ml recycling bottle*1
- Optional Accessory
- Transparent bath cover, Vacuum pump, Recirculating chiller
