Laminar Flow Cabinet

Horizontal Laminar Flow Cabinet BBS-H1300 BBS-H1800

Model BBS-H1300 BBS-H1800

Laminar Flow Cabinet is used only for sample protection. Laminar Flow Cabinet is a work bench or similar enclosure, which creates a particle-free working environment by taking air through a filtration system and exhausting it across a work surface in a laminar or unidirectional air stream.

Power
400W / 500W
Noise
<65dB
Dimensions
1300*820*2040mm / 180…
A tailored quote, without the guesswork.

Ask about availability, configuration and delivery to your location. We reply personally.

Request a quote
Enquiry only. No payment is taken.
  • Specifications confirmed with you before any order
  • International delivery arranged to your facility
  • Personal sourcing support from first message to arrival
A closer look

About this equipment

Technical Parameters:

Model BBS-H1300 BBS-H1800
External Size(W*D*H) 1300*820*2040mm 1800*820*2070mm
Internal Size(W*D*H) 1200*500*570mm 1700*500*570mm
Work Surface Height

750mm
Display

LCD display
Airflow Velocity

Average of 0.3~0.5m/s

Material

Main Body: Cold-rolled steel with anti-bacteria powder coating

Work Table: 304 stainless steel

Side and Front Window: 5mm toughened glass, anti-UV
Pre-filter

Polyester fiber, washable
HEPA Filter

99.995% efficiency at 0.3μm
Noise

<65dB
Front Window

Motorized
Max Opening

430mm
LED Lamp 12W*1 16W*2

UV Lamp

 30W*1 30W*1

Emission of 253.7 nanometers
Consumption 400W 500W
Waterproof Socket

Two, total load≤500W
Caster

Universal caster with leveling feet
Power Supply

AC220V±10%, 50/60Hz; 110V±10%, 60Hz
Standard Accessory

LED lamp, UV lamp*2, Base stand, Gas tap, Waterproof socket*2, Water tap(only for BBS-H1800)
Optional Accessory

Electric height adjustable base stand
Gross Weight 254kg 328kg
Package Size(W*D*H) 1450*1060*1650mm 1950*1060*1600mm
The details

Specifications

Model
BBS-H1300 / BBS-H1800
External Size(W*D*H)
1300*820*2040mm / 1800*820*2070mm
Internal Size(W*D*H)
1200*500*570mm / 1700*500*570mm
Work Surface Height
750mm
Display
LCD display
Airflow Velocity
Average of 0.3~0.5m/s
Material
Main Body: Cold-rolled steel with anti-bacteria powder coating
Material
Work Table: 304 stainless steel
Material
Side and Front Window: 5mm toughened glass, anti-UV
Pre-filter
Polyester fiber, washable
HEPA Filter
99.995% efficiency at 0.3μm
Noise
<65dB
Front Window
Motorized
Max Opening
430mm
LED Lamp
12W*1 / 16W*2
UV Lamp
30W*1
UV Lamp
Emission of 253.7 nanometers
Consumption
400W / 500W
Waterproof Socket
Two, total load≤500W
Caster
Universal caster with leveling feet
Power Supply
AC220V±10%, 50/60Hz; 110V±10%, 60Hz
Standard Accessory
LED lamp, UV lamp*2, Base stand, Gas tap, Waterproof socket*2, Water tap(only for BBS-H1800)
Optional Accessory
Electric height adjustable base stand
Gross Weight
254kg / 328kg
Package Size(W*D*H)
1450*1060*1650mm / 1950*1060*1600mm
